Syrotech GPON 1110 WDONT WiFi router specially designed to provide high-speed internet connectivity of up to 300 Mbps without latency. Gigabit passive technology, which are able to support high bandwidth applications such as HD Gaming, streaming, and Voice Over Internet Protocol (VOIP) service. Integrated with Omni directional external antenna helps to increase range and bandwidth. These GPON ONT are enclosed with WPA/WPA2 firewalls to enhance security and Web UI for easy configuration. Its sleek and compact design make it an ideal choice for homes and small business and those who looking for a fast and reliable network.
KEY FEATURES
- Enclosed with Late port Limitation and Loop detection
- Integrated with IGMP Proxy and MLD Snooping
- Dual Stack configuration support on both IPV4 and IPv6 address
- Support Bridging, Routing, and Bridge mixed mode
- Complaint with Line testing according to GR-909
- NAT, ACL, and Firewall for security enhancement
- Support VLAN tag, transparent, and trunk mode
TECHNICAL SPECIFICATION
|
Brand |
SYROTECH |
|
|
Model |
GPON 1110 WDONT |
|
|
Function |
Modem |
|
|
Type |
Wireless |
|
|
Bandwidth |
300 Mbps |
|
|
Frequency |
Single Band |
|
|
Internet connection |
Bridging & Routing |
|
|
CPU |
400 MHz |
|
|
Flash |
128M NAND |
|
|
Memory |
128M bytes DDR3 |
|
|
Interface |
PON |
GPON, GEPON, SC Single Mode (Dual mode), Upstream 1.25Gbps, Downstream 2.5Gbps |
|
LAN |
|
|
|
WIFI |
|
|
|
Wavelength |
TX 1310nm, RX1490nm |
|
|
Sensitivity |
<-7dBm (CLASS B+) |
|
|
Overload |
> 8 dBm (CLASS B+) |
|
|
Operating |
Temperature |
-5~+55℃ |
|
Humidity |
10~90%(non-condensing) |
|
|
Storage |
Temperature |
-30~+60℃ |
|
Humidity |
10~90%(non-condensing) |
|
|
LEDs |
PWR,PON, LOS,LAN1~LAN2, PHONE,Pair,WiFi |
|
|
Power consumption |
12V,1A |
|
|
Dimension |
185mm*33mm*122mm（W*H*D） |
|
|
Weight |
280 g |
|
Syrotech WDONT series specially designed for Bsnl broadband and FTTH solution for homes and small-scale businesses. Integrated Gigabit Passive Optical Technology (GPON), which makes it increase of transmission range upto 20 Km with Upstream of 1.25 Gbps and downstream of 2.5 Gbps. This technology will provide high-speed internet of 300 Mbps, through this users enjoy smooth and reliable internet surfing, VOIP, HD gaming, and online streaming without any low latency.
This Wifi modem also enclosed with advanced features such as VLAN Modes ( Trunk, Transparent, Tag), L3 capability, QoS, Multicast, and security firewalls along with Management functions. Built with Omni directional External antenna that enhances wireless connectivity range and sensitivity. In terms of cost, this Syrotech modem is affordable when compared to other brands with unique features as mentioned.
OTHER INTERFACES
|
Layer 2 Functions |
|
|
Multicast |
|
|
L3 Functions |
|
|
QOS |
|
|
Security |
|
|
VOIP |
|
|
WIFI |
|
|
Management |
|
ORDER INFORMATION
|
Model |
Description |
Power Adaptor Input |
|
Syrotech SY-1110 WDONT |
1GE+1FE+1POT+WIFI |
220V AC, 50HZ |
