These Wi-Fi 6 access points provide high-performance connectivity for IoT and mobility requirements in any organization. Each delivers peak data rates of 2.69Gbps, ensuring speed and reliability in any enterprise environment.
Combined peak data rate up to 2.69Gbps
Security enhancements for Enhanced Open and WPA3
Built-in technology resolves sticky clients on Wi-Fi 6 and 5
Multiuser OFDMA and MU-MIMO for increased fidelity
Supports Bluetooth 5 and Zigbee for IoT
Accurate indoor location via embedded ranging technology
Enhances Wi-Fi performance and reduces airtime contention between clients. It features Orthogonal frequency-division multiple access (OFDMA), multi-user MIMO and cellular optimization. These provide up to 4 spatial streams (4SS) and 160MHz channel bandwidth (VHT160).
Handles multiple Wi-Fi 6 clients simultaneously, regardless of client type or device.
Clients share channels by using smaller sub-carriers or resource units (RU), and are not competing for airtime and bandwidth.
Utilize multiple single and dual-stream clients simultaneously by supporting downlink MU-MIMO (5GHz radio).
AI-powered ClientMatch technology steers clients to the best AP by identifying the strongest radio signal.
Based on client capabilities, ClientMatch steers traffic from noisy 2.4 GHz to 5 GHz or 6 GHz.
Besides dynamic traffic steering, ClientMatch also optimizes AP load balancing.
Through AirMatch, bandwidth dynamically adjusts to support changing device density, enhances roaming via Effective Isotropic Radiated Power (EIRP), and minimizes co-channel interference through real-time channel assignments.
ACC - Advanced Cellular Coexistence
Built-in filtering reduces the impact of interference from cellular networks, DAS, and small cells.
IPM ( Intelligent Power Monitoring )
Energy consumption is constantly monitored by APs. Also, they can configure based on available PoE power - handy when wired switches run out.
For greater scalability, security, and manageability, unified APs can operate as standalone access points.
With zero-touch provisioning & cloud-based solution, branch offices & remote workers can easily deploy APs without any technical expertise.
Provides a single pane of glass for managing wired and wireless LANs, WANs, and VPNs in Aruba ESP (Edge Services Platform).
Natively built in Advanced security, end-to-end orchestration, and AI-powered analytics.
Supports Bluetooth 5 and 802.15.4 radios (for Zigbee support) for easier IoT-based asset tracking, security solutions, and location tracking.
Allow organizations to leverage IoT platforms without requiring an overlay infrastructure or additional IT staff.
Include TWT to schedule client communications with Aps
WPA3 & Enhanced Open: Latest version of WPA provides enterprise networks with stronger encryption and authentication. With Enhanced Open, passwords and data on guest networks are automatically encrypted for seamless new security.
WPA2-MPSK: Simplifies WPA2 passkey management:- If Wi-Fi password changes on one device, no changes are needed on others. Note:- Requires ClearPass Policy Manager.
VPN Tunnels: As a VPN concentrator, this establishes a secure SSL/IPSec tunnel to the Remote AP (RAP-VPN).
TPM (Trusted Platform Module): Ensure secure storage of credentials and boot code.
OTHER WIFI FEATURES:
Transmit beamforming (TxBF) improves signal reliability and range
Passpoint Wi-Fi (Release 2) offers seamless cellular-to-Wi-Fi carryover for guests
Dynamic frequency selection optimizes RF spectrum
Maximum Ratio Combining improves receiver performance
CDD/CSD provides improved downlink RF performance
Increasing reception and range with Space-Time Block Coding
External dual band antenna connectors (A0 through A3) for 4 (female) RP-SMAs. Internal loss (due to duplexing circuitry) between radio interface and external antenna connectors: 1.3dB in 2.4GHz and 1.7dB in 5GHz.
Horizontal planes (top view) show azimuth patterns (0 degrees) and downtilt patterns (30 degrees).
Side view of vertical planes (elevation planes with antennas rotated 0 and 90 degrees) (averaged patterns for all antennas)
HPE smart rate RJ45 port negotiates a speed of upto 2.5 Gbits per second.
Auto-sensing link speed (100/1000/2500BASE-T) and MDI/MDX
2.5Gbps speed meets the specifications of NBase-T and 802.3bz
EEE (Energy Efficient Ethernet interface (RJ-45)) - Auto-sensing of link speed and MDI/MDX 802.3az
USB Port (2.0): Sources upto 1A / 5W to attached devices.
VISUAL INDICATOR: Includes two multi-color LEDs to show system status.
Reset Button: Factory reset, LED mode switch (normal/off)
Transmit Power (IoT)
BLE (5.0): Transmission up to 8dBm (class 1), receiving up to -95dBm.
Zigbee (802.15.4): Up to 8 dBm transmitting power, -97 dBm receiving power.
With a downtilt angle of 30 degrees, the vertical polarized omnidirectional antenna Peak gains 4.9 dBi
At +25C operating temperature, the Mean Time Between Failures (MTBF) is approximately 560,000 hours (64 years).
POWER SOURCE AND CONSUMPTION:
DC power and PoE are both available, DC power takes precedence
AP is unrestricted when powered by DC or 802.3at (class 4)/802.3bt (class 5) PoE.
AP will start up unrestricted when Powered by PoE, but restrictions may apply depending on PoE budget and actual power. IPM restrictions can be applied in any order.
Note: Power sources are sold separately from the devices.
Software version: Aruba InstantOS 220.127.116.11 ( With Some Restriction)
