Aruba CX6200F-24/48-Port SFP L3 Non-PoE Enterprise Managed Switches
- Description
- Shipping & Returns
- Reviews
Aruba CX6200F-24G-4SFP and 48G-4SFP are enterprise-grade managed access switches engineered to deliver secure, resilient, and high-speed connectivity for branch offices, small enterprises, and campus edge deployments. The CX6200F-24G-4SFP provides 24 Gigabit RJ-45 ports with 4 SFP uplinks, while the CX6200F-48G-4SFP features 48 Gigabit RJ-45 ports with 4 SFP uplinks, enabling flexible uplink options and network expansion.
Powered by the Aruba AOS-CX operating system, the CX6200F series supports advanced Layer 2 and Layer 3 functionality, automated configuration, and streamlined monitoring. These switches offer scalable performance, robust traffic management, and comprehensive security features, ensuring reliable operation for mission-critical applications. With cloud-based management through Aruba Central and support for stacking, the CX6200F series allows simplified deployment, efficient administration, and future-proof network growth for evolving enterprise environments.

CX6200F-24G (S0M81A)

CX6200F-48G (S0M83A)
KEY FEATURES:
- Total Ports: 24 × 10/100/1000BASE-T + 4 × 1G SFP uplinks (CX6200F-24G) / 48 × 10/100/1000BASE-T + 4 × 1G SFP uplinks (CX6200F-48G)
- PoE Support: Non-PoE (fixed models)
-
Switching Capacity: Up to 176 Gbps
-
Forwarding Rate: Up to 130 Mpps
-
CPU: Quad-core ARM Cortex A72 @ 1.8 GHz
-
System Memory: 8 GB DDR4 SDRAM
-
Onboard Storage: 16 GB eMMC
-
Packet Buffer: 16 MB
-
MAC Address Table: Up to 64,000 entries
-
VLAN Support: Up to 4,094 VLANs
-
Jumbo Frames: Supports frames up to 9,216 bytes
-
Latency: 1 Gbps: ~2.3 µs; 10 Gbps: ~1.4 µs
-
High Availability: VSF stacking up to 8 members; fixed internal power supply and fans
-
Airflow Options: Front-to-back cooling
-
Advanced Features: Layer 2/3 switching, OSPF, static routing, VRRP, QoS, ACLs, dynamic segmentation, and streaming telemetry
TECHNICAL SPECIFICATIONS:
SPECIFICATION |
CX6200F-24G (S0M81A) |
CX6200F-48G (S0M83A) |
Ports |
24 × 10/100/1000BASE-T + 4 × 1G SFP |
48 × 10/100/1000BASE-T + 4 × 1G SFP |
PoE Power |
Non-PoE |
Non-PoE |
Processor |
Quad-core ARM Cortex A72 @ 1.8 GHz |
Quad-core ARM Cortex A72 @ 1.8 GHz |
Memory |
8 GB DDR4 SDRAM |
8 GB DDR4 SDRAM |
Flash Storage |
16 GB eMMC |
16 GB eMMC |
Switching Capacity |
128 Gbps |
176 Gbps |
Forwarding Rate |
~95 Mpps |
~130 Mpps |
Latency |
<3 µs |
<3 µs |
Management Ports |
1 × RJ-45 console, 1 × USB-C, 1 × USB Type-A |
Same |
Power Supply |
Fixed internal |
Fixed internal |
Input Voltage |
100–127 VAC / 200–240 VAC |
100–127 VAC / 200–240 VAC |
Cooling |
Fixed fans |
Fixed fans |
PERFORMANCE:
SPECIFICATION |
DETAILS |
Switching Capacity |
128 Gbps (24G) / 176 Gbps (48G) |
Forwarding Rate |
~95 Mpps (24G) / ~130 Mpps (48G) |
Latency |
Sub-3 µs (64-byte packets) |
QoS Support |
Prioritization for latency-sensitive apps (voice, video, data) |
Energy Efficiency |
IEEE 802.3az compliant |
SECURITY:
SPECIFICATION |
DETAILS |
Authentication |
802.1X, MAC authentication, captive portal |
Access Control |
ACLs, role-based access control (RBAC) |
Encryption |
Secure management via SSH, HTTPS |
Monitoring |
RADIUS, TACACS+, sFlow, NAE-based monitoring |
MANAGEMENT:
SPECIFICATION |
DETAILS |
Network OS |
Aruba AOS-CX |
Automation |
Zero-Touch Provisioning (ZTP), REST APIs, Ansible |
Monitoring |
Aruba Central cloud-based management |
Telemetry |
Streaming telemetry with analytics |
Protocol Support |
STP, RSTP, MSTP, LLDP, LACP, IPv4/IPv6 management |
PHYSICAL AND ENVIRONMENTAL:
SPECIFICATION |
DETAILS |
Dimensions |
4.39 × 44.2 × 32.7 cm (both models) |
Weight |
4.8 kg (24G) / 5.1 kg (48G) |
Operating Temp |
0°C to 40°C (32°F to 104°F) |
Storage Temp |
-40°C to 70°C (-40°F to 158°F) |
Relative Humidity |
5% to 95% non-condensing |
Noise Level |
Low-noise fixed fans |
Compliance |
CE, FCC, VCCI, UL, RoHS |
ADVANCED FEATURES:
High-Performance Edge Connectivity:
The Aruba CX6200F-24G-4SFP and CX6200F-48G-4SFP provide enterprise-grade Layer 2 and Layer 3 switching designed for branch, campus edge, and small business networks. With support for VLANs, link aggregation (LACP), and jumbo frames, these switches ensure fast, reliable, and efficient traffic handling. Their robust architecture allows seamless expansion and integration with larger Aruba deployments.
Centralized and Automated Network Control:
Built on the Aruba AOS-CX operating system, the CX6200F series supports Aruba Central management, enabling automated configuration, real-time monitoring, and orchestration. Features like Zero Touch Provisioning (ZTP), REST API programmability, and VSF stacking reduce manual configuration, accelerate deployment, and simplify operational management across multiple sites.
Comprehensive Security and Access Management:
Security is enforced through 802.1X network authentication, ACLs, RBAC, and TACACS+/RADIUS integration. Management access is encrypted via HTTPS and SSH, protecting sensitive administrative operations. These features ensure secure connectivity for users and devices while maintaining compliance with enterprise security policies.
Resilient Hardware for Continuous Operation:
With VSF stacking of up to 8 members, redundant internal power systems, and high-reliability fan configurations, the CX6200F switches deliver consistent uptime. Their hardware design minimizes risks of failure, supporting uninterrupted network services in mission-critical deployments.
Advanced Traffic Optimization:
The switches offer sophisticated QoS features for prioritizing real-time traffic, including voice, video, and collaboration applications. Dynamic traffic shaping and congestion management ensure predictable performance even under heavy network load, maintaining high-quality user experiences.
Energy-Aware and Eco-Friendly Design:
Aruba CX6200F switches implement IEEE 802.3az Energy Efficient Ethernet standards to dynamically optimize power consumption. This reduces operational costs while supporting sustainable IT initiatives without compromising network performance or reliability.
Scalable Architecture for Future Growth:
With flexible uplink options, VSF stacking, and non-blocking architecture, the CX6200F series provides enterprise-grade scalability. Organizations can expand network capacity easily, ensuring long-term investment protection and smooth integration with existing Aruba infrastructure for growing branch or campus environments.
ORDERING INFORMATION:
PART NUMBER/SKU |
DESCRIPTION |
CX6200F-24G/S0M81A |
Aruba CX6200F Switch – 24 × 1G RJ-45 + 4 × 1G SFP uplinks, fixed internal PSU, non-PoE |
CX6200F-48G/S0M83A |
Aruba CX6200F Switch – 48 × 1G RJ-45 + 4 × 1G SFP uplinks, fixed internal PSU, non-PoE |
WARRANTY & SUPPORT:
Manufacturers are responsible for warranties, which are based on the purchase date and validity. We make sure the products we sell are delivered on time and in their original condition at Grabnpay. Whether it's physical damage or operational issues, our team will help you find a solution. We help you install, configure, and manage your devices. We'll help you file a warranty claim and guide you every step of the way.
All listed prices reflect standard market rates. Final commercial terms, including volume-based discounts, will be provided based on purchase volume, MOQ, and other applicable criteria. For more information about switches & other accessories, contact our technical support team.
