HPE Aruba Remote AP 505H client match OFDMA ,WPA, MPSK ,Dual band,2x2 MIMO Support Bluetooth 5.0 & zigbee for IOT capabilities

The Wi-Fi 6 access points offer high-performance connectivity for mobile, cloud, and IoT-demanding organizations. With wireless data rates up to 1.5 Gbps and gigabit wired ports, they are perfect for hotels, dormitories, and remote offices.

SPECIFICATION:



KEY FEATURES:

•  Compact design that combines wireless and wired access.
•  Suitable for home-based and teleworking initiatives.
•  Up to 1.5 Gbps maximum wireless throughput can be achieved.
•  4 wired network ports and 1 Smart Rate uplink port.
•  Secure network with WPA3 and enhanced open.
•  Resolves sticky client issues on both Wi-Fi 6 and Wi-Fi 5.
•  Multi-user efficiency enhanced through OFDMA.
•  IoT support for Bluetooth 5 and Zigbee.
•  Fiber backhaul add-on for Aruba Fiber Media Converter.

DEVICE COMPATIBILITY:

OFDMA:

•  Ability to handle multiple Wi-Fi 6 clients simultaneously regardless of the type of traffic on each channel.
• A subcarrier or resource unit (RU)  optimizes channel utilization so clients share bandwidth and airtime.

Client Optimization:

• Identifying the best Wi-Fi 6 compatible AP based on AI, ClientMatch eliminates sticky clients.
• In roaming, session metrics guide mobile devices to the best AP based on bandwidth, traffic types, and application types.

Advanced Cellular Coexistence (ACC):

An integrated filtering system automatically minimizes interference from cellular networks, DASs, and small cells.

Intelligent Power Monitoring (IPM):

Power consumption is continuously monitored and reported. Also configurable based on PoE power - ideal when wired switches have exhausted their power budget.

IoT PLATFORM CAPABILITIES

1. Supports GPS, asset tracking, security, and IoT sensor syncing via Bluetooth 5 and 802.15.4 (for Zigbee support). It can be used as an IoT platform without requiring additional IT resources.
2. Target Wake Time (TWT): Reduces airtime contention for IoTs that communicate infrequently with APs and optimizes client power consumption.
3. Advanced IoT Coexistence (AIC): Enhances Ability to operate Wi-Fi, Bluetooth, and Zigbee radios at maximum capacity without interfering with each other.

SECURITY:

WPA3: Latest version of WPA offers better encryption and authentication for enterprise networks.

Enhanced Open: Automatically encrypts passwords and sessions in order to secure them against unauthorized access.

WPA2-MPSK: Passkey management is simpler - changing the Wi-Fi password on one device does not require changing it on others.

  NOTE: ClearPass Policy Manager is required to use this feature.

VPN Tunnels: RAPs and IAP-VPNs establish SSL/IPSec VPN tunnels with Gateways and Mobility Controllers serving as VPN concentrators.

TPM (Trusted Platform Module): Application that provides secure storage for credentials, keys, and boot codes.

CONNECTIVITY: Supports up to 256 associated clients per radio (a total of 512 clients). Depending on the environment, maximum client density varies.

HYBRID WORK:

• EdgeConnect Microbranch provides a consistent employee experience regardless of location.

• SD-WAN optimization, security, and manageability are enhanced through Aruba Central and  Aruba AP itself.

• Extend remote access point capabilities by integrating SASE with cloud security services such as Zscaler.

OTHER INTERFACES:

Wifi Antenna:

• 2x2 MIMO integrated semi-directional antennas with 5.2dBi peak single antenna gain at 2.4GHz and 5.4dBi at 5GHz.
• Built-in antennas are designed to be mounted on a wall or desk. 
• A combined, average pattern of the antenna patterns in MIMO radios has a peak gain of 3.3dBi in 2.4GHz and 2.9dBi in 5GHz.

Antenna patterns averaged for all antennas along the vertical plane 0 (looking at the side of the AP, facing right)





Vertical (elevation) plane 90 (looking at the front of the AP) (averages for all antennas)

Ethernet Port:

Uplink: E0: Smart Rate Ethernet wired network port (RJ45)

• Intelligent link speed detection (100/1000/2500BASE-T) and MDI/MDX
• Complies with NBase-T and 802.3bz specifications at 2.5Gbps
• Energy-efficient Ethernet (EEE) on IEEE 802.3az
• POE-PD: 48 volts DC (nominal) 802.3 af/at/bt (class 3, 4 or 6) POE (class 3, 4 or 6)

Local: (E1-E4): Four Ethernet wired network ports (RJ45)

•  Automatic sensing link speed (10/100/1000BASE-T) and MDI/MDX
•  Energy Efficient Ethernet with standard 802.3az
•  POE-PSE: 802.3af/at POE output; either dual 802.3af (both ports) or single 802.3at (E1).

BLE5.0 &  Zigbee (802.15.4):

•  BLE: Transmits up to 7dBm (class 1), receives up to -100dBm (125kbps).
•  Zigbee: Power up to 7dBm, receiving power up to -97dBm (250kbps)
•  Integral semi-directional antenna with 1.2 dBi peak gain.

DC power interface: 48Vdc (nominal, +/- 5%) with 1.35mm/3.5mm center-positive circular plugs (9.5mm length).

Visual indicators: Display status of Power/System, Radio, POE-PSE status, and 4 Local network ports.

Reset button: Reset factory settings, LED mode change (Normal/OFF)

Serial console interface: USB micro-B physical port, proprietary

Reliability: 780khrs (88yrs) at +25C operating temperature( MTBF).

POWER SOURCE

• Supports both POE and direct DC power.
• When both are available, POE power gets priority.
• Work without restrictions when powered by DC or 802.3bt (class 6) POE
•  USB port disabled (only) when powered by 802.3at (class 4) POE and with IPM disabled, and support (802.3af) POE-PSE power on E1 only (no PSE on E2).
• USB port and POE-PSE capabilities are disabled when powered by 802.3af (class 3) POE with IPM disabled.
• With IPM enabled, it starts without restrictions but dynamically applies additional restrictions based on POE budget and actual power consumption.

Worst-case power consumption (without USB or PSE / max):

•   DC : 14W / 50W
•   POE  (802.3bt): 14W / 51W
•   POE  (802.3at): 14W / 25.5W
•   POE  (802.3af): 13.5W / 13.5W

 IDLE MODE:

•   POE Powered: 6.2W

 DEEP SLEEP MODE:

•   POE Powered: 3.5W

MECHANICAL FEATURE:

Dimension: 86mm (W) x 47mm (D) x 150mm (H) (without mount bracket)

Weight      : 360g

Shipping:

Dimension: 111mm (W) x 54mm (D) x 167mm (H)

Weight      : 450g
